Option
SIP Log Server IP Address Enter the Log Server IP address where the SIP Log data for the router will be
SIP Log Server port
Ingress Gain
Egress Gain

VoIP Functionality

This section describes how to use the VoIP function of the DSL router in more detail. Some features involve 2 or 3 parties. In
that case, note that all 3 parties have to be successfully registered.

Registering

Before using any VoIP functions, the DSL router has to register itself to a registrar. The DSL router also has to be configured
with a proxy, which relays VoIP signalling to the next hop. In fact, many implementations integrate these two into one server,
so in many case registrar and proxy refer to the same IP.
1 Select the right interface to use for registering, depending on where proxy/registrar resides. If use WAN link, ensure
that it is already up.
2 Select the checkbox of Use SIP Registrar, and fill in the IP address and port with the right value.
3 Fill the extension information: Authentication name, Password, Cid Name and Cid Number.
4 Click Apply to take the settings into effect.
5 TEL indicator of VoIP service should be on, indicating that SIP client is successfully registered.

Placing a Call

This section describes how to place a basic VoIP call.
1 Pick up the receiver on the phone.
2 Hear the dial-tone. Dial the extension of remote party.
3 To end the dialling, wait for digit timeout, or just press # immediately.
4 After the remote party answers the call, you are in voice connection.
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP
Figure 106 – SIP Debug Settings page
sent to.
Enter the port to be used for transmitting the SIP Log data.
Setting allow control of Speaker volume on handset.
Settings allow control of Microphone volume on handset.
Table 36 – SIP Debug Settings table
Definition
