Field
Last Member
Query Interval
Robustness Value The robustness variable is a way of indicating how susceptible the subnet is to lost
Maximum
Multicast Groups
Maximum
Multicast Data
Sources
Maximum
Multicast Group
Members
Fast Leave Enable With IGMP fast-leave processing, which means that the router immediately

IPSec

Displays the IPSec tunnel connections.
74 of 131
© NetComm Wireless 2017
a) Allows controlling the amount of IGMP reports sent during a time window.
b) Engages the report suppression feature, which permits a host to suppress its own
report and conserve bandwidth.
IGMP uses this value when router hears IGMP Leave report. This means that at
least one host wants to leave the group. After router receives the Leave report, it
checks that the interface is not configured for IGMP Immediate Leave (single-host
on the segment) and if not, it sends out an out-of-sequence query.
packets. IGMP can recover from robustness variable minus 1 lost IGMP packets.
You can also click the scroll arrows to select a new setting. The robustness variable
should be set to a value of 2 or greater.
The default robustness variable value is 2.
The maximum number of multicast groups that the router can control at any one
time.
The maximum number of data sources a multicast group can have.
The maximum number of hosts a multicast group can have.
removes the interface attached to a receiver upon receiving a Leave Group
message from an IGMP host.
Table 27 – Multicast settings table
Figure 92 – IPSec Tunnel Mode Connections list
Definition
