Item
VLAN Mux ID
IPv6
IGMP Pxy
IGMP Source Enable
MLD Pxy
MLD Source Enable
NAT
Firewall
Status
IPv4 Address
IPv6 Address
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP
Details the status of VLAN Mux ID if used.
The status of IPv6.
Details the status of IGMP on each WAN connection. IGMP is only used with IP
v4 connections. IGMP proxy enables the router to issue IGMP host messages on
behalf of hosts that the router discovered through standard IGMP interfaces,
allowing NAT transversal of Multicast traffic.
Details the status of IGMP Src on each WAN connection. IGMP Sources function
send a membership report that includes a list of IGMP source addresses.
Shows the status of the Multicast Listener Discovery protocol when IPv6 is in
use. Multicast Listener Discovery (MLD) proxy enables the router to issue MLD
host messages on behalf of hosts that the router discovered through standard
MLD interfaces.
Details the status of MLD Src on each WAN connection.
MLD Sources function can send a membership report that includes a list of MLD
source addresses.
The NAT status of the WAN connection.
The status of the router firewall across the WAN connection.
The status of the WAN connection.
The current IP v4 address of the WAN interface.
The current IP v6 address of the WAN interface.
Table 9 – WAN Info table
Definition
