20 Select Management > Reboot. Click the Reboot button to restart the router and save the new settings.
21 To test your Quality of Service settings try running speed-tests (http://speedtest.net) on both PCs/devices
simultaneously.

Limiting the upstream rate

1 By default, a QoS queue is created when a WAN interface is created but it is disabled by default. On the QoS Queue
page, enable the queue for the appropriate WAN interface.
2 On the QoS Classification page, add a rule to limit the upstream rate, for example:
Classification Criteria:
Class Interface: LAN
Ether type: IP
Classification Results:
Class Queue: the queue that was enabled in Step 1
Set rate-limit: set according to your preference
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP
Figure 138 – QoS Queue details
Figure 139 – Network Traffic Class Rule
