Wireless Setup Guide
Login to the web user interface
1
Connect a computer and the NF17ACV using an Ethernet cable. (A yellow Ethernet cable was provided with your
NF17ACV).
2
Open a web browser (such as Google Chrome or Mozilla Firefox), type the following address into the address bar and
press Enter.
http://192.168.20.1
3
Enter the following credentials in the User Name and Password fields:
User Name:
admin
Password:
admin
Note – If no authentication prompt is displayed or you see a request time out message, refer to "What if I cannot access Web User
Interface guide" from FAQs section.
NF17ACV FAQs
Wireless Setup Guide
Login screen
NF17ACV FAQs
1 of 7
© NetComm Wireless 2017
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NetCommWireless NF17ACV
Summary of Contents for NetCommWireless NF17ACV
- Page 1 Wireless Setup Guide Login to the web user interface Connect a computer and the NF17ACV using an Ethernet cable. (A yellow Ethernet cable was provided with your NF17ACV). Open a web browser (such as Google Chrome or Mozilla Firefox), type the following address into the address bar and press Enter.
- Page 2 WiFi 2.4GHz / WiFi 5GHz The NF17ACV allows you to maintain separate wireless settings for both 2.4GHz and 5GHz wireless services. Select the service you want to use (or both) and separately configure them: 2.4 GHz Wireless configuration pages 5 GHz Wireless configuration pages We recommend that you access the web interface over a wired connection (using Ethernet cable) to change the WiFi security key/password.
- Page 3 Confirm that Enable Wireless and Enable Wireless Multicast Forwarding (WMF) are selected. The default SSID (network name) on this example is “NetComm 8386”. You may change the SSID and press the “Apply/Save” button. NF17ACV FAQs 3 of 7 © NetComm Wireless 2017...
- Page 4 Wireless – Security To find your WiFi security key, navigate to Wireless > 2.4GHz/5GHz > Security. Click the "Click here to display" link next to the WPA/WAPI passphrase to find your current WiFi password. A pop up window will display your current WiFi password. The configuration on the modem is now complete.
- Page 5 Enter the WiFi security key/password and click Next. Your computer connects to the WiFi network. If you are facing difficulty to connect the Wi-Fi network name, refer to “Wireless Troubleshooting Guide” from FAQs section. NF17ACV FAQs 5 of 7 © NetComm Wireless 2017...
- Page 6 Apple iPhone The following is an example of connecting to the WiFi network using an Apple iPhone. On your iPhone, navigate to settings and tap “Wi-Fi”. When Wi-Fi is turned on, your phone scans for available nearby networks. Tap your WiFi network name/SSID [1] (in this example, it is “NetComm 8386”), enter the WiFi password [2] and press Join [2].
- Page 7 Airport icon again. Your WiFi network has a tick next to its name. The wireless network configuration is complete and you can now use the Internet. You can disconnect the Ethernet cable, if you wish. NF17ACV FAQs 7 of 7 © NetComm Wireless 2017...
