No. Interface
7 Power supply jack

Left Side

No
1
2
3
16 of 131
© NetComm Wireless 2017
Connection point for the included power adapter. Connect the power supply
here.
Table 6 – Rear interface table
1
Figure 2 – NF18ACV router side view
Interface
2.4G WPS button
5G WPS button
On/Off button
Table 7 – Side interface table
Description
2
3
Description
Press the 2.4G WPS button to activate the WPS
PBC pairing function for the 2.4GHz radio.
Press the 5G WPS button to activate the WPS
PBC pairing function for the 5GHz radio.
Toggles the power on and off.
