NetCommWireless NF10WV Setup Manual

Vdsl / adsl n300 wifi gateway with voip generic voip setup guide

Hide thumbs Also See for NF10WV:

Table of Contents

Download this manual See also: User Manual, Setup Manual

Configuring your NF10WV for VOIP Service

You need your VoIP account details to be able to configure VoIP Service, please contact your SIP provider or Internet Service

provider if you do not have the VoIP account details.

The following steps will take you through the process of setting up your VOIP connection.

Open a web browser (such as Internet Explorer, Google Chrome or Firefox), type http://192.168.20.1 into the address

bar and press enter.

At the login screen, type admin into both the User Name and the Password fields and click Log In.

Please ensure that your NF10WV is running the latest firmware version, you can find the latest firmware version for

NF10WV from the following link:

http://support.netcommwireless.com/product/NF10WV

Click Voice from the left-hand side menu and then click SIP Basic Setting:

NF10WV FAQs

Generic VoIP Setup Guide

NF10WV FAQs

1 of 4

Table of Contents

Do you have a question about the NF10WV and is the answer not in the manual?

Page 1 At the login screen, type admin into both the User Name and the Password fields and click Log In. Please ensure that your NF10WV is running the latest firmware version, you can find the latest firmware version for NF10WV from the following link: http://support.netcommwireless.com/product/NF10WV...
Page 2 Please select the correct Bound Interface Name from your Internet WAN Service Connection or you can select Any_WAN Please note for SIP Domain Name: Please leave it blank unless required by your VoIP Provider. Tick Use SIP Proxy for SIP Account 1, Use SIP Outbound Proxy for SIP Account 1 and Use SIP Registrar for SIP Account 1 and fill them with the SIP Domain name as given by your VoIP Provider.
Page 3 Please click SIP Advance Setting and ensure Enable RTCP Flow Control is ticked and DTMF Relay Setting is RFC2833 and SIP Transfer Protocol is UDP. Click the Apply button. NF10WV FAQs 3 of 4 © NetComm Wireless 2017...
Page 4 If all the settings are correct then please click VoIP Status and you should see Registration Status as UP, it means the VoIP is running and ready to be used. Check for a dial tone on your phone handset. The VoIP account should now be active and you should now be able to make and/or receive VoIP phone calls (depending on the type of VoIP account you are using).
