Figure 4 - Nf18Acv Router - Select Adsl As Wan Connection Type; Figure 5 - Select Pppoe As Wan Mode; Figure 6 - Enter Pppoe User Id And Password - NetCommWireless NF18ACV User Manual

b Select either the PPPoE, PPPoA or Bridging for your internet connection as specified by your Internet Service
Provider (ISP).
Click the Next button.
c In the User ID and Password fields, enter the PPPoE authentication username and password assigned to you by
your Internet Service Provider (ISP).
Click the Finish button.
d The account settings are saved and the NF18ACV connects to the internet.
22 of 131
© NetComm Wireless 2017
Figure 4 – NF18ACV router – Select ADSL as WAN connection type
Figure 5 – Select PPPoE as WAN mode
Figure 6 – Enter PPPoE User ID and Password
User Guide
