Services Control

The Service Control List (SCL) allows you to enable or disable your Local Area Network (LAN) or Wide Area Network (WAN)
services by ticking the checkbox as illustrated below and specifying the service port assign to the service.
The following access services are available: FTP, HTTP, ICMP, SAMBA, SNMP, SSH, TELNET, and TFTP.
Click the Apply/Save button after making any changes to continue.
Note – You should change your default password, before enabling a WAN service.
Management – Update Firmware
The following screen appears when selecting the Update Firmware option from the Management menu. By following this
screen's steps, you can update your modem's firmware. Manual device upgrades from a locally stored file can also be
performed using the following screen.
1 Obtain an updated software image file from:
2 Click the Choose File button to locate the image file.
3 Click the Update Firmware button once to upload and install the file.
108 of 131
© NetComm Wireless 2017
Figure 124 – Service Control List (SCL)
