- Page 1 NF3ADV VoIP Setup Guide (for GoTalk)
- Page 2 Configuring your NF3ADV for GoTalk VoIP The following steps will take you through the process of setting up your VoIP connection. This guide assumes that the NF3ADV already has an active internet connection. Step 1: Checking Computer Network Settings: You will need to connect your computer directly to your VoIP device (modem or ATA) and set the network connection on your computer to obtain an IP address automatically.
- Page 3 Below are the instructions for setting Windows 7 to obtain an IP address automatically for your ethernet connection: 1. Click on the Start Menu, and go to “Control Panel”. Click on “Network and Sharing Centre”. (If you only see "Network and Internet", open that first, and then click on "Network and Sharing Centre".) 3.
- Page 4 Step 2: Configuring your VoIP settings: 1. Navigate to http://192.168.1.1 in a web browser. 2. Enter “admin” as both the username and password and press the Login button.
- Page 5 3. Select the “Switch to VoIP/NAS View” option at the bottom of the screen. 4. Select the “Service Domain” option from the “SIP Setting” menu. 5. Enter the following details as provided by your VoIP Service Provider: ITEM DEFINITION If you wish to use more than one VoIP account select the Multiple VoIP Accounts” option or to use a single SIP Account VoIP account select the “1 SIP Account”...
- Page 6 6. Press the Save button at the bottom of the screen. Select the “Switch to Advanced View” button at the top of the screen. 7. Select the Reboot option from the Toolbox menu to reboot the router. 8. After logging back into the router, check that the VoIP Status is now “Registered” (as the example above shows).
