Replacing the top tron-lighting
cable
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your
computer, follow the instructions in
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.

Procedure

1 Align and place the top tron-lighting cables on the chassis.
2 Adhere the tape that secures the top tron-lighting cables to the chassis.
3 Route the top tron-lighting cables through the routing-guides on the chassis.
4 Connect the top tron-lighting cables to the logo board.

Post-requisites

1 Replace the
2 Replace the
3 Replace the
4 Replace the
5 Replace the left and right side-panels. See
6 Replace the
base panel.
rear bezel.
front bezel.
handle bars.
stability foot.
computer. After working inside your
After working inside your
"Replacing the side panels".
169
