Procedure
NOTE: Note the routing of all cables as you remove them so that you
can route them correctly after you replace the system board. For
information on system-board connectors, see
components".
1
Lay the chassis on the right side.
2
Disconnect all the cables connected to the system-board assembly.
3
Remove the nine screws (#6-32x6) that secure the system-board assembly
to the chassis.
130
"system-board
