Keysight Technologies E4417A Service Manual page 34

Test Setup
Figure 2-4
Procedure
Use the following procedure to perform the instrument accuracy (average path)
test:
The procedure details the key presses required on the Keysight E4416A. For the
NOTE
Keysight E4417A the equivalent key presses should be performed on both
channels.
1 Connect the equipment as shown in
2 Switch the power meter on.
3 Preset the instrument:
4 Set the display units to watts:
Keysight E4416A/E4417A Power Meters Service Guide
Power Meter
CHANNEL A
Instrument Accuracy (Average Path) Test Setup
Preset
Press then
Confirm
Local
Meas
Press ,
Units
Display
Range Calibrator
Power sensor cable
Figure
.
, .
W
Performance Tests
2-4.
