Modification Recommended
Service Note
E4980A 2 MHz Precision LCR Meter
Serial Numbers: MY46516722 – MY46617916, SG46500800 – SG46600805
Manufacturing ID Number: N/A
E4980A cannot power on due to PSU malfunction
Parts Required:
P/N
Description
0950-5428
Power Supply AC 125-Watt 5-Output
ADMINISTRATIVE INFORMATION
ACTION
[X] ON SPECIFIED FAILURE
CATEGORY:
[[]] AGREEABLE TIME
LOCATION
[[]] CUSTOMER INSTALLABLE
CATEGORY:
[[]] ON-SITE
(active On-site contract required)
[X] SERVICE CENTER
[[]] CHANNEL PARTNERS
AVAILABILITY: PRODUCT'S SUPPORT LIFE
[[]] Calibration Required
[X] Calibration NOT Required
ADDITIONAL INFORMATION:
Qty.
1
STANDARDS
LABOR: 1.0 Hour
SERVICE:
[[] RETURN
INVENTORY:
[[]] SCRAP
[[]] SEE TEXT
NO CHARGE AVAILABLE UNTIL: 31-Mar-2020
PRODUCT LINE: WN
AUTHOR: jm
© Keysight Technologies 2015-2019
Modification Recommended Service Note
Version 1.2 | March 15, 2019| Page 1 of 2
E4980A-16
Supersedes:
NONE
USED
[X] RETURN
PARTS:
[[]] SCRAP
[[]] SEE TEXT
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Keysight Technologies E4980A
Summary of Contents for Keysight Technologies E4980A
- Page 1 Service Note Supersedes: NONE E4980A 2 MHz Precision LCR Meter Serial Numbers: MY46516722 – MY46617916, SG46500800 – SG46600805 Manufacturing ID Number: N/A E4980A cannot power on due to PSU malfunction Parts Required: Description Qty. 0950-5428 Power Supply AC 125-Watt 5-Output...
- Page 2 4. When PSU malfunction is identified, replace the PSU by 0950-5428. See Power on Sequence Troubleshooting, and Power Supply Assembly Replacement in E4980A/E4980AL Precision LCR Meter Service Guide for more details. 5. Return the defective PSU via PRP Revision History:...
