Ú Note:
Any calibrations made here will ONLY be applied locally
to this unit. Other devices on the network will not have these
offsets applied.

External Alarm Setup

The Siren Enabled option must be set in order for the unit to
activate the buzzer when an alarm condition arises. Its setting also
determines the operation of the external alarm output.
Echosounder setup
Make general settings from the Echosounder Settings dialog. Define
and configure Echosounder sources in the Installation dialog.
Overlay downscan
When a HDI transducer with DownScan is connected to your
system, you can overlay DownScan images on the regular
Echosounder image.
When activated, the Echosounder menu expands to include basic
DownScan options.
Structure depth offset
Setting for Structure transducers.
All transducers measure water depth from the transducer to the
bottom. As a result, water depth readings do not account for the
distance from the transducer to the lowest point of the boat in the
water or from the transducer to the water surface.
To show the depth from the lowest point of the boat to the bottom,
do the following. Before setting the Structure offset, measure the
distance from the structure transducer to the lowest point of the
boat in the water. If, for example, the distance is 0.3 m (1 ft), it will be
input as (minus) - 0.3 m (-1 ft).
To show the depth from the water surface to the bottom, do the
following. Before setting the Structure offset, measure the distance
from the structure transducer to the water surface. If, for example,
the distance is 0.3 m (1 ft), it will be input as (plus) 0.3 m (1 ft).
A setting of 0 (zero) causes the depth displayed to be the distance
from the transducer to the bottom.
