Simrad GO XSE Installation Manual page 68

68
Storage temperature -20°C to +60°C (-4°F to +140°F)
Waterproof rating IPx7 and IPx6
Shock and vibration 100 000 cycles of 20 G
GPS
Interface
Ethernet/Radar
Physical
Dimensions (W x H x D) Refer to "Dimensional drawings" on
Weight (display only)
Mounting type Bracket (supplied) or panel
Technical specifications
Humidity IEC 60945 Damp heat 66°C
(150°F) @ 95% relative (18 hr)
10 Hz high speed update
(internal)
WASS, MSAS, EGNOS, GLONASS
5" unit Not available
7" unit 1 port (5 pin connector)
9" unit 1 port (5 pin connector)
12" unit 1 port (5 pin connector)
NMEA 2000 1 port (Micro-C)
Sonar 1 port (9 pin connector)
Data card slot
5" unit 1 slot (microSD)
7" unit 1 slot (microSD)
9" unit 2 slot (microSD)
12" unit 2 slot (microSD)
Wireless Internal 802.11b/g/n
page 69
5" unit 0.53 kg (1.16 lbs)
7" unit 0.91 kg (2 lbs)
9" unit 1.32 kg (2.9 lbs)
12" unit 2.22 kg (4.90 lbs)
mount
| GO XSE Installation Manual
