Simrad GO XSE Installation Manual page 12
Hide thumbs
Also See for GO XSE:
- Operator's manual (204 pages) ,
- Installation manual (84 pages) ,
- Getting started (41 pages)
Table of Contents
Advertisement
12
6
Protective caps
2x - 5" unit
3x - 7", 9" and 12" units
7
Documentation package
•
Installation manual
•
Quick guide
•
Mounting template
8
A: Bracket mounting kit - 5" unit
•
Quick Release Bracket
•
Mounting screws (4x #10 x 3/4" PN HD SS)
B: Bracket mounting kit - 7" and 9" units
•
U bracket (plastic)
•
Mounting screws (4x #10 x 3/4" PN HD SS)
•
Bracket knobs (2x)
C: Bracket mounting kit - 12" unit
•
U bracket (metal)
•
Mounting screws (4x #10 x 3/4" PN HD SS)
•
Bracket knobs (2x)
Check the contents
