Panel mounting
The screws and gasket used for panel mounting are included in the
box.
For mounting instructions, refer to the mounting template.
Bezel fitment and removal
The bezel trim have been designed to be very low profile, and
therefore fully conceal the locking tabs that keep it from being
accidentally disengaged from the mounting flange. To release the
locking tabs, gently insert a thin object between the bezel and the
screen frame. When the first locking tab is released and an opening
is visible, carefully release the remaining locking tabs and remove
the bezel.
20
Installation
| GO XSE Installation Manual
