8
Technical specifications
Ú Note:
The most up-to-date specifications list is available at:
www.simrad-yachting.com
All units
Approvals
Display
Viewing angles in degrees
(typical value @ contrast ratio = 10)
Electrical
Supply voltage 12 V DC (10 - 17 V DC min - max)
Recommended fuse rating 3 A
Power consumption
Environmental
Operating temperature range -15°C to +55°C (+5°F to +131°F)
Technical specifications
Compliance "Compliance statements" on page 3
Resolution
5" unit 800 x 480
7" unit 800 x 480
9" unit 800 x 480
12" unit 1280 x 800
Type TFT Widescreen
Brightness >1200 nits
Touch screen Full touch screen (multi-touch)
Left/right: 70, top: 50, bottom:
60
Protection Protection reverse polarity and
temporary over-voltage to 18 V
5" unit 12 W (900 mA @ 13.5 V)
7" unit 12 W (900 mA @ 13.5 V)
9" unit 12 W (900 mA @ 13.5 V)
12" unit 20 W (1500 mA @ 13.5 V)
| GO XSE Installation Manual
67
