D
CAN actuation of the system bus according to ISO-DIS 11898 (CAN High Speed)
E
The resolver interface is suitable for the connection of standard resolvers with the
following specifications:
Input impedance > 95 Ω at 8 kHz, number of pole pairs up to 7,
30 000 rpm at number of pole pairs = 1
Excitation voltage U
Input voltage U
Phase shift (at excitation frequency): 7° (5 kHz), 14° (10 kHz), 26° (20 kHz)
Tripping resistance > 2.4 kΩ (PTC) acc. DIN 44081,
PTC thermistor or bimetal temperature sensor (normally closed contact)
Use PTC thermistors with safe insulation from the motor winding acc. to
EN 61800 5-1.
4.3.2
The control and software functionality can be freely configured for economical opera-
tion with a safe function.
Caution!
Attention! In order to minimize electromagnetic interference and to obtain a good
12
12
Communication interface system bus
Resolver- and PTC thermistor input (SubD9)
= 3.5 V, I
REF rms
= 1.8 V, voltage proof up to 30 V
min rms

Control terminals

Expansion module EM-RES-03
The control inputs and outputs must be connected and disconnected free
of electrical power. Otherwise components may be damaged.
signal quality, the line screen is to be connected to PE on a plane at both
ends.
= 60 mA
max
Wieland DST85 / RM3,5
0.2 ... 0.3 Nm
1.8 ... 2.7 lb-in
EM-RES-03
EM-RES-03
0.14 ... 1.5 mm
2
AWG 30 ... 16
0.14 ... 1.5 mm 2
AWG 30 ... 16
0.25 ... 1.0 mm 2
AWG 22 ... 18
0.25 ... 0.75 mm 2
AWG 22 ... 20
