If a PC or a PLC is used as a master, the identifiers of the Rx/Tx-SDO1 can be
adapted by parameterization on the frequency inverter.
Attention: In free assignment of identifiers, there may not be any double occu-
The setting of the identifiers of the RxSDO1 is done via the parameter
Identifier
No.
921 RxSDO1-Identifier
The setting of the identifiers of the TxSDO1 is done via parameter number 922.
No.
922 TxSDO1-Identifier
The setting "0" results in identifier assignment according to the Predefined Connec-
tion Set.
The second SDO channel can be deactivated via the
0 - SDO2 deactivated
1 - SDO2 activated
The identifier assignment for the second SDO channel is always to the
specification:
Identifier Rx-SDO2
Identifier Tx-SDO2
Note:
28
28
pancy !
The identifier range 129...191 may not be used as the emergency tele-
grams can be found there.
921.
Parameter
Description
Parameter
Description
Operation mode
= 1600 + Node-ID
= 1472 + Node-ID
In this way, firm identifiers via which communication takes place are
available for the visualization tool.
EM-RES-03
Min.
0
Min.
0
SDO2 Set Active
Function
Communication channel deactivated
Communication channel activated for the visuali-
zation tool
EM-RES-03
RxSDO1-
Setting
Max.
Fact. sett.
2047
0
Setting
Max.
Fact. sett.
2047
0
923.
10/07
10/07
