Control Inputs And Outputs; Analog Input Em-S1Ina; General; Characteristic - BONFIGLIOLI Vectron Manual

6
6.1
6.1.1
The analog input of the EM-RES-03 expansion module can optionally be configured as
a voltage or a current input. Parameterization of the input signal is done by the defini-
tion of a linear characteristic and assignment as a
−
−
−
−
6.1.2
The mapping of the analog input signals onto a frequency or percentage reference
value is possible for various demands. The parameterization is to be done via two
points of the linear characteristic of the reference channel.
The characteristic point 1, with the coordinates X1 and Y1, and the characteristic point
2, with the coordinates X2 and Y2, can be set in four parameters.
The characteristic points X1 and X2 are stated as percentages, as the analog input can
be switched as a current or voltage input via switch S3.
The coordinates of the characteristic points are related as a percentage to the analog
signal, with 10 V or 20 mA, and the parameter
ter
done via the digital inputs of the frequency inverter and/or by selecting the character-
istic points.
The definition of the analog input characteristic can be calculated via the two-point
form of the straight-line equation. The speed Y of the drive mechanism is controlled
according to the analog control signal X.
Attention! Monitoring of the analog input signal via the parameter
52
52

Control inputs and outputs

Analog input EM-S1INA

General

reference value source
(can be selected via the parameter
reference percentage source
(can be selected via the parameter
actual percentage source
(can be selected via the parameter
tion x11) or
limit value sources
(can be selected via the parameters 734...737).

Characteristic

Parameter
No. Description
564 Characteristic point X1
565 Characteristic point Y1
566 Characteristic point X2
567 Characteristic point Y2
Maximum reference percentage
=
Behavior
563 demands a check of the characteristic parameters. Sensible
use is only possible if the
range.
Reference frequency source
Reference percentage source
Actual percentage source
Min.
-100.00 %
-100.00 %
-100.00 %
-100.00 %
Maximum Frequency
519. The change of direction of rotation can be
Y2 - Y1
( )
Y ⋅ X − X1 +
X2 - X1
Characteristic point X1
EM-RES-03
EM-RES-03
475),
476),
478, in configura-
Setting
Max. Fact. sett.
100.00 % -98.00 %
100.00 % -100.00 %
100.00 % 98.00 %
100.00 % 100.00 %
419 or parame-
Y1
Error/Warning
564 is in the positive
10/07
10/07
