Frequency Inverter (18.5 To 30 Kw); Control Terminals - BONFIGLIOLI Active ACT 201-05 Brief Manual

5.5.3
5.6
The control and software functionality can be freely configured to ensure a reliable
and economical operation. The operating instructions describe the factory settings of
the standard connections in the relevant
parameters to be set up.
Caution!
•
•
06/05
06/05

Frequency Inverter (18.5 to 30 kW)

Connection of brake resistor with temperature switch

Control Terminals

Switch off power supply before connecting or disconnecting the keyed
control inputs and outputs. Otherwise, components may be damaged.
The unit may only be connected with the power supply switched off.
Make sure that the frequency inverter is discharged.
Configuration
Control Terminals
Wieland DST85 / RM3,5
0.2 ... 0.3 Nm
1.8 ... 2.7 lb-in
X2
U V W
Rb1 Rb2
R
b
Rb1 Rb2
T1 T2
30 as well as the software
0.14 ... 1.5 mm
AWG 30 ... 16
0.14 ... 1.5 mm
AWG 30 ... 16
0.25 ... 1.0 mm
AWG 22 ... 18
0.25 ... 0.75 mm
AWG 22 ... 20
2
2
2
2
29
29
