6.1.5
The analog input characteristic with change of sign of the reference value can be
adapted by the parameter
to be defined extends the zero crossing of the speed relative to the analog control
signal. The percentage parameter value is relative to the maximum current or voltage
signal.
No.
560 Tolerance band
-10V
(-20mA)
Without tolerance band
The
factory extends the parameterized tolerance band to the hysteresis.
pos. min. value
neg. min. value
With tolerance band and minimum value
For example, the output variable resulting from the positive input signals is kept at the
positive minimum value until the input signal is below the value for the tolerance band
in a negative direction. After that proceed on the set characteristic.
10/07
10/07

Tolerance band and hysteresis

Tolerance band
Parameter
Description
(X2 / Y2)
pos. max. value
(X1 / Y1)
neg. max. value
Minimum Frequency
418 or the
(X2 / Y2)
pos. max. value
Tolerance band
(X1 / Y1)
neg. max. value
EM-RES-03
560 of the application. The tolerance band
Min.
0.00 %
pos. max. value
+10V
-10V
(+20mA)
(-20mA)
With tolerance band
Minimum reference percentage
EM-RES-03
Setting
Max. Fact. sett.
25.00 % 2.00 %
(X2 / Y2)
+10V
Tolerance band
(X1 / Y1)
neg. max. value
518 set in the
