SIS ™ Operation, cont'd

Symbol definitions

= CR/LF (carriage return/line feed) (0x0D 0A)
• = space
= On/off status
X1
= RS-232 port number
X2
= n = –1= redirect serial port data from the specified port to allow
X3
for a transparent pass through mode. The response is returned
with leading zeroes.
n = the maximum number of serial ports that the IP link supports.
is verified at this port.
X5
= Time (in 10 ms increments) to wait for receive data before
X4
releasing the port to another source (min = 1 [10 ms],
maximum = 32767 [32.767 seconds], default = 10 [100 ms]).
= Numerical value (nnnn) to set L (length of message to receive) or
X5
assign as a D (delimiter).
L = number of byte count (min = 0, max = 32767, default = 0).
D = decimal number for ASCII character (min = 0,
maximum = 00255, default = 00000L).
The numeric value directly precedes the identifier; for example:
to specify a 3-byte length or
0A. The identifier, "L" or "D" is case sensitive and must be uppercase.
= Firmware version
X6
= Verbose firmware version-description-upload date/time. See
X7
= Voltage 1 (3.3 V), Voltage 2 (12.0 V),
X8
= Verbose/response mode
X9
The default value is 0 for telnet and 0 for RS-232.
X9
If tagged responses are enabled, all read commands return the constant
string plus the data, the same as setting the value. For example, the MKP
responds Ipn• to the
X18
= Security level
X10
www.camboard.de
4-6 MKP 3000 Remote Control Panel • SIS
0 = off/disable
1 = on/enable
1 = host
2 = switcher
= "3L"
X5
= "10D" to specify an ASCII delimiter of
X5
Bootstrap version (x.xx)
page 4-10.
Temperature (degrees Fahrenheit)
(xxx.xx), Voltage 3 (5.0 V)
0 = no password assigned
1 = verbose mode
2 = tagged responses for queries
3 = 1 and 2 (verbose and tagged)
•CN command.
Esc
0 = clear/none
11 = user password assigned
12 = administrator password assigned
™
Operation
CAMBOARD Electronics
X11
X12
X13
X14
X15
X16
X17
X18
X19
X20
X21
Tel. 07131 911201
Fax 07131 911203
= Baud rate 300, 600, 1200, 1800, 2400, 3600, 4800,
9600 (default), 14400, 19200, 28800,
38400, 57600, or 115200
= Parity (1st character only) Odd, Even, None (default), Mark,
Space
= # of data bits 7, 8 (default)
= # of stop bits 1 (default), 2
= Input or output number 0 through 999
= Name 11 characters maximum for inputs
and outputs
12 characters maximum for presets
24 characters maximum for MKP
name.
Upper and lower case alphanumeric
characters and " " + – : = / and
spaces are valid.
The following characters are invalid in the name:
+ ~ , @ = ' [ ] { } < > ' " ; : | \ and ?.
= Preset number
= Default name Factory default name
(combination of the model name
+ last 3 pairs of MAC address).
= Time and date (set) MM/DD/YY-HH:MM:SS
where:
MM = month: 01 (Jan.) — 12 (Dec.)
DD = day: 01 through 31
YY = year: 00 through 99
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59
= Time and date (read) Day,•DD•Mmm•YYYY•HH:MM:SS
where:
Day = weekday: Mon through Sun
DD = day: 01 through 31
Mmm = month: Jan through Dec
YYYY = year: 2000 through 2099
HH = hour: 00 through 24
MM = minutes: 00 through 59
SS = seconds: 00 through 59
= GMT offset –12.0 through +14.0. Hours and
minutes removed from GMT
