Installation, cont'd
Extron
MKP 3000 MAAP
Panel
Figure 2-16 — Mounting the MKP 10 MAAP
2. See figure 2-17 at right. If you have not already done so,
connect the serial control and power cables between the J1
connector ( ) on the MKP 10 MAAP and the Remote
1
Keypad port ( ) on the rear of the MKP 3000 MAAP.
2
www.camboard.de
2-16 MKP 3000 Remote Control Panel • Installation
CAMBOARD Electronics
Extron
MKP 10
Front Panel
I / O
3
2
1 6
5
C T
P O L E 4
9
W E S E
R E
R
S E P 8
A A
T
E L
0 M 7 N C
0 0 C A
P 3 0
M K
C K
B A
P 1 0
M K
(4) #4-40
Extron
Screws
n
t r o
MKP 10
E x
Module
Tel. 07131 911201
Fax 07131 911203
1
Figure 2-17 — MKP 3000 MAAP rear panel with
MKP 10 MAAP mounted
MKP 10 MAAP J1 control connector
1
MKP 3000 MAAP Remote Keypad port
2
3. Mount the MKP 3000 MAAP (with the mounted
MKP 10 MAAP) to the wall box or mounting bracket. See
"Mounting the MKP to the mounting bracket (mud ring)
or wall box," earlier in this chapter.
ce-info@camboard.de
MKP 3000 Remote Control Panel • Installation
2
2-17
