Local Operation, cont'd
When you unlock the control panel, the MKP 3000
enters setup mode. Make changes if desired and then
press the Take button to exit.
For an an MKP 3000 connected to an MKP 10 MAAP:
1. On the MKP 10 MAAP, press and hold the 1, 3, Back, and
Cancel buttons until the MKP 3000 LCD window displays
the name of the executive mode that has been set
approximately 3 seconds). (Admin Mode and User Mode
are displayed briefly; Panel Locked remains displayed.)
2. If necessary, repeat step 1 until the LCD window indicates
the mode you want.

Rear Panel Resets

Performing soft resets

The remote control panel has three soft resets available that
restore various tiers of MKP settings to their default settings.
• Events (mode 3) reset — Restarts the communications
and control events.
• IP system (mode 4) reset — IP system reset resets most IP
protocols to their default settings.
IP system reset clears the Internet protocol (IP) settings,
but does not reset the target address, the host control
setting, the priority setting, or any user-loaded files.
• Absolute (mode 5) reset — Performs all of the system
reset functions and clears the MKP's IP address to
192.168.254.253 and its subnet mask to 255.255.0.0. This
function is identical to the SIS command
chapter 4, "SIS ™
Perform a soft reset of the MKP as follows:
1. Press and hold the Reset (R) button until the Reset LED
blinks off once (events reset), twice (IP system reset), or
three times (absolute reset) (figure 3-8).
www.camboard.de
3-16 MKP 3000 Remote Control Panel • Local Operation
ZQQQ
Esc
Operation").
CAMBOARD Electronics
(see
Tel. 07131 911201
Fax 07131 911203
Press and hold
the Reset button.
3
Events seconds
R
(Mode 3)
Reset
Press and hold
the Reset button.
6
IP System seconds
R
(Mode 4)
Reset
Press and hold
the Reset button.
9
Absolute seconds
R
(mode 5)
Reset
Figure 3-8 — Performing soft resets
2. Release the Reset button and then immediately press and
release the Reset button again. Nothing happens if the
second momentary press does not occur within 1 second.

Performing a hard reset

The hard reset restores the MKP to the original factory default
firmware configuration and erases all user-installed software or
firmware. (A hard reset does not perform all possible MKP
reset functions.)
CAUTION Ensure that you have backed up any locally-created
HTML, JavaScript, or other files that you have
uploaded to the MKP's user file space before you
perform the hard reset. A hard reset will erase all
locally-created files from the MKP.
Perform a hard reset as follows:
1. If necessary, turn off power to the switcher.
2. Press and hold the Reset button on the rear panel while
you apply AC power to the MKP (figure 3-9).
ce-info@camboard.de
MKP 3000 Remote Control Panel • Local Operation
R
LED flashes
Release, then
once.
immediately
press and
R
release again.
R
LED flashes
Release, then
twice.
immediately
press and
R
release again.
R
LED flashes
Release, then
three times.
immediately
press and
R
release again.
3-17
