Serial Interface Bypass
If a serial protocol has been selected, then a Serial Interface Bypass toggle box is displayed. When the
Serial Interface Bypass toggle box is checked, the currently selected serial protocol will not be used during
the alert origination. A message in the Origination Table above changes to say the Serial Protocol is
bypassed.
Audio record and upload interface
When the toggle box for Display audio record and upload interface is checked, there are two options:
Record Audio File and Upload Audio .WAV file to DASDEC II Server.
1.
2.
136
Encoder > Send Alert> General Alerts, bottom of web page
Record Audio File (Optional). Clicking this button causes a new, temporary page to display. The
page provides controls for recording audio with a microphone or from the line input. The recording
input source must be set up prior to use. The set up page is under Setup > Audio > Encoder.
There is a link to the Setup page on the record file page. If microphone input is selected, then a
microphone must be connected to the correct microphone input jack at the back of the DASDEC II.
To record, enter a unique name for the audio file in the "New Audio Filename" text field. (A
unique file name is one not already used in the provided "Select Audio File" selection box.
If you use an existing name, the original file by that name will be overwritten.)
Push the
minutes. The DASDEC II will automatically cut off recording at 2 minutes.
Click on the
selection box.
Preview the file using the "Preview Selected" button.
Once the file is correct, select it from the Audio File selection box. In the previous screen
shot, the file abduction2.wav is selected.
Upload Audio .WAV file to DASDEC II Server. You can upload a pre-recorded digital audio file (in
the .wav format) from your local host computer file system using the provided Upload Audio .WAV
file to DASDEC II server interface at the bottom of the page. The browse button will use your
browser's file system navigator to find an audio file. Once the file is selected, click
. The file will then appear in the Audio file lists.
button and speak. The duration of this file must be under two (2)
button when complete. The file will appear in the Audio File
