How to Order

4 How to Order

4.1 Ordering Form

4.1.1 Drive Configurator
It is possible to design an adjustable frequency drive
according to the application requirements using the
ordering number system.
Order the adjustable frequency drive as either standard or
with integral options by sending a type code string
describing the product to the local Danfoss sales office.
The type code is a string of characters describing the
configuration, for example:
-102N132KT4E21H1XGCXXXSXXXXAGBKCXXXXDX
From the online drive configurator, a customer can
configure the right adjustable frequency drive for a given
application and generate the type code string. The drive
configurator automatically generates an 8-digit sales
number to be delivered to the local sales office.
Another option is to establish a project list with several
products and send it to a Danfoss sales representative.
The tables of type codes and configuration options
includes frame sizes A, B, and C. For detailed information
on those frame sizes, see the relevant design guide.
MG16C122
Design Guide
Example of a Drive Configurator Interface Set-up:
The numbers shown in the boxes refer to the letter/figure
position in the type code string, read from left to right.
Product groups
Adjustable frequency drive series
Power rating
Phases
AC line voltage
Enclosure
RFI filter
Brake
Display (LCP)
Coating PCB
Line power option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
C0 options, MCO
C1 options
C option software
D options
Table 4.1 Type Code Character Positions
Danfoss A/S © Rev. 2014-01-13 All rights reserved.
4
1-2
3-5
8-10
6-9
10-11
12-14
15-16
17
18
19
20
22
23
24-27
28
29-30
31-32
33-34
35
36-37
38-39
71
