How to Order
Description
Software language
1): Available for all D frames.
Table 4.2 Ordering Type Code for D-frame Adjustable frequency drives
Description
Product group
Drive series
Power rating
Phases
AC line voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Line power option
Adaptation
Adaptation
Software release
Software language
A options
B options
C options
0
C options
1
C option software
MG16C122
Design Guide
Position Possible Choice
28
Pos Possible choice
1–3 FC
4–6 102
8–10 450–630 kW
11 Three phases (T)
11- T 4: 380–500 V AC
12 T 7: 525–690 V AC
13- E00: IP00/Chassis - for installation in external enclosure
15 C00: IP00/Chassis (for installation in external enclosure) w/ stainless steel
backchannel
E21: IP 21/NEMA Type 1
E54: IP 54/NEMA Type 12
E2M: IP 21/NEMA Type 1 with line power shield
E5M: IP 54/NEMA Type 12 with line power shield
16- H2: RFI filter, class A2 (standard)
17
H4: RFI filter class A1
18 B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals
19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel (D frames IP00 and IP 21 only)
20 C: Coated PCB
21 X: No line power option
3: Line power disconnect and fuse
5: Line power disconnect, Fuse, and Load sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
22 Reserved
23 Reserved
24- Current software
27
28
29–30 AX: No options
A0: MCA 101 Profibus DP V1
A4: MCA 104 DeviceNet
AN: MCA 121 Ethernet IP
31–32 BX: No option
BK: MCB 101 General purpose I/O option
BP: MCB 105 Relay option
BO:MCB 109 Analog I/O option
BY: MCO 101 Extended Cascade Control
33–34 CX: No options
35 X: No options
5: MCO 102 Advanced Cascade Control
36–37 XX: Standard software
