Danfoss VLT HVAC Drive FC 102 Design Manual page 144

How to Install
Terminal Locations - Frame Sizes F1 and F3
Take the following position of the terminals into consideration when designing the cable access.
5 5
Figure 5.74 Terminal Locations - Inverter Cabinet - F1 and F3. Connector Plate is 1.65 in [42 mm] below .0 Level.
1 Front Side
2 Left Side
3 Right Side
Table 5.57 Legend to Figure 5.74
Figure 5.75 Regeneration Terminal Locations - F1 and F3
142
Design Guide
1
6
Danfoss A/S © Rev. 2014-01-13 All rights reserved.
2
308.3 [12.1]
253.1 [10.0]
180.3 [7.1]
.0 [.0]
44.40 [1.75]
244.40 [9.62]
4 Ground bar
5 Motor Terminals
6 Brake Terminals
DC '-'
1739.1
805.0
765.0
1694.1
DC '+'
1654.1
710.0
3
4
5
4
MG16C122
