- Page 1 I=jN `~êÉ=~åÇ=ÅäÉ~åáåÖ=áåëíêìÅíáçåë=Ñçê=íÜÉ=éê~ÅíáÅÉ=íÉ~ã båÖäáëÜ...
-
Page 2: General Information
Use only care and cleaning agents as well as lubricants which are approved by SIRONA. A continuously updated list of approved agents can be downloaded from the Sirona Internet homepage under REF 59 70 905: š www.sirona.com If you do not have Internet access, you can use one of the following two ways to order the list: •... -
Page 3: Table Of Contents
Sirona Dental Systems GmbH Contents Care and cleaning instructions for the practice team C2 , M1 Contents Connection box ......................Cuspidor........................Vacuum system ......................Care ..............................Disinfection with a dry suction system ....................Disinfection with a wet suction system ..................... - Page 4 Overview Sirona Dental Systems GmbH Care and cleaning instructions for the practice team C2 , M1 Overview The numbers indicated in the overview correspond to the chapter numbers in the table of contents. Thus you can easily find the work to be performed in this document.
-
Page 5: Connection Box
Sirona Dental Systems GmbH 1 Connection box Care and cleaning instructions for the practice team C2 , M1 Connection box Replacing the water and air filters If you notice any changes in media flows, please check the water and air filters (1) for permeability. Replace them if necessary. -
Page 6: Cuspidor
Before refitting the tumbler outlet or the hydrocolloid adapter, lightly lubricate the O-rings. ATTENTION Use only lubricants which have been approved by Sirona (see page 2, General information)! 59 58 512 D 3370 D 3370.103.01.13.02... -
Page 7: Vacuum System
Sirona. ATTENTION Use only cleaning and disinfecting agents which have been approved by Sirona (see page 2, General informa- tion)! Do not use any washing powder or other disinfec- tants! •... -
Page 8: Disinfection With A Wet Suction System
• Finally, reinsert the gold trap. ATTENTION Use only cleaning and disinfecting agents which have been approved by Sirona (see page 2, General informa- tion)! Do not use any washing powder or other disinfec- tants! simultaneously 59 58 512 D 3370 D 3370.103.01.13.02... -
Page 9: Suction Handpieces
Grease the O-rings at the joints afterwards! Weekly Separate the suction handpiece at the joint, clean it and and grease the joints. ATTENTION Use only lubricants which have been approved by Sirona (see page 2, General information)! 59 58 512 D 3370 D 3370.103.01.13.02... -
Page 10: Cleaning The Suction Hoses
Before refitting the hoses, grease the O-rings on the connection pieces. ATTENTION Use only lubricants which have been approved by Sirona (see page 2, General information)! The hoses must engage firmly. If the unit is equipped with a 3rd suction hose, clean it the same way. -
Page 11: Thermodisinfecting The Suction Hoses
For the saliva ejector hose, insert the intermediate piece (8) in the hose holder (9). Lubricate the O-rings. ATTENTION Use only lubricants which have been approved by Sirona (see page 2, General information)! Grease Fit the hose holders onto the rails in the thermodisinfec- tor (by Miele) as illustrated. -
Page 12: Amalgam Separation
4 Amalgam separation Sirona Dental Systems GmbH 4.1 Replacing the amalgam separator Care and cleaning instructions for the practice team C2 , M1 Amalgam separation Replacing the amalgam separator When AMALG lights up on the display on the dentist ele-... -
Page 13: Cleaning The Siphon
Sirona Dental Systems GmbH 4 Amalgam separation Care and cleaning instructions for the practice team C2 , M1 4.2 Cleaning the siphon NOTE Regardless of whether AMALG lights up on the display or not, the rotor (3) in the amalgam separator must be re- placed at least once a year. -
Page 14: Instrument Hoses
5 Instrument hoses Sirona Dental Systems GmbH 5.1 Removal/Replacement of instrument hoses Care and cleaning instructions for the practice team C2 , M1 Instrument hoses Removal/Replacement of instrument hoses Switch the unit OFF before removing the hoses! Unscrew the cap nut (1) and then simply pull off the instrument supply hoses. -
Page 15: Highspeed Handpiece Hose
Sirona Dental Systems GmbH 5 Instrument hoses Care and cleaning instructions for the practice team C2 , M1 5.3 Highspeed handpiece hose • Clean the Sprayvit nozzle according to the operating in- structions or • Have the dental unit checked by a service engineer. -
Page 16: Disinfection System
6 Disinfection system Sirona Dental Systems GmbH 6.1 Microbiological water test Care and cleaning instructions for the practice team C2 , M1 Disinfection system Microbiological water test Must be performed after a working pause of more than one week. Use a “Total Count Tester” for this purpose. -
Page 17: Purge/Auto Purge Function (Purging The Water Paths)
Sirona Dental Systems GmbH 6 Disinfection system Care and cleaning instructions for the practice team C2 , M1 6.2 Purge/Auto Purge function (purging the water paths) Purge/Auto Purge function (purging the water paths) PURGE function (only for dentist element) The purge function enables you to flush the water paths. - Page 18 6 Disinfection system Sirona Dental Systems GmbH 6.2 Purge/Auto Purge function (purging the water paths) Care and cleaning instructions for the practice team C2 , M1 Auto Purge (APURGE) function The Auto Purge function offers possibility of automated purging of all water carrying instruments in the dentist element, of the assistant Sprayvit and of the tumbler fill- ing unit.
- Page 19 Sirona Dental Systems GmbH 6 Disinfection system Care and cleaning instructions for the practice team C2 , M1 6.2 Purge/Auto Purge function (purging the water paths) On pressing quick setting key 1 briefly (< 3 s), the fol- lowing prompt appears if all instruments are deposited in...
-
Page 20: Sanitation
(1.4%) during sanitation. ATTENTION If the connected devices are not suitable for this higher sanitation concentration, Sirona recommends discon- necting them from the treatment center during sanitation and performing a separate sanitation in accordance with the manufacturer’s specifications. - Page 21 Sirona Dental Systems GmbH 6 Disinfection system Care and cleaning instructions for the practice team C2 , M1 6.3 Sanitation Sanitation The sanitation process can be controlled either from the dentist or assistant element. The instructions for the assistant element are indicated in parentheses.
-
Page 22: Electric Motors
6 Disinfection system Sirona Dental Systems GmbH 6.3 Sanitation Care and cleaning instructions for the practice team C2 , M1 • Place the sanitation bowl with cover on the cuspidor. The sanitation bowl container must always be clean! • Insert the cleaning adapters for the instrument cou-... - Page 23 Sirona Dental Systems GmbH 6 Disinfection system Care and cleaning instructions for the practice team C2 , M1 6.3 Sanitation • Attach the suction hose (10) and the saliva ejector hose and, if available, the 3rd suction hose (11) to the side of the cleaning adapter (3).
- Page 24 6 Disinfection system Sirona Dental Systems GmbH 6.3 Sanitation Care and cleaning instructions for the practice team C2 , M1 Sanitation phase 4: DESIN The water tank is automatically filled with DENTOSEPT P subsequently. The SAN key on the assistant element lights up.
- Page 25 Sirona Dental Systems GmbH 6 Disinfection system Care and cleaning instructions for the practice team C2 , M1 6.3 Sanitation As soon as the message DESINF PROCESS COMPLETE ( RETURN INSTR. ( appears on the display the instruments can be returned PROCESS COMPLETE to their holders.
-
Page 26: Surfaces / O-Rings
The cleaning agent also performs care simultaneously. ATTENTION Use only cleaning agents which have been approved by Sirona (see page 2, General information)! Disinfection: ATTENTION Use only disinfectants which have been approved by Si-... - Page 27 Sirona Dental Systems GmbH 7 Surfaces / O-rings Care and cleaning instructions for the practice team C2 , M1 Disinfecting the surfaces The surfaces can be spray and wipe disin- fected with surface disinfectants. Intensive cleaning and disinfection of the head...
- Page 28 (197°F), the instrument racks on the dentist and assis- tant elements can be removed. ATTENTION Use only cleaning agents which have been approved by Sirona (see page 2, General information)! Assistant element The instrument rack can be removed by pulling on the catch.
-
Page 29: Satelec Mini L.e.d. Curing Light
ATTENTION 3 min Use only cleaning and disinfecting agents which have been approved by Sirona (see page 2 , General informa- tion)! The connecting cable at the end of the handpiece can be removed by turning it (see illustration below). -
Page 30: Sirocam 3 / Sivision 3 Video Camera And Monitor
9 SIROCAM 3 / SIVISION 3 video camera and monitor Sirona Dental Systems GmbH 9.1 Care and cleaning of the SIROCAM 3 Care and cleaning instructions for the practice team C2 , M1 SIROCAM 3 / SIVISION 3 video camera and monitor... -
Page 31: Care And Cleaning Of The Sirocam C
Disinfecting ATTENTION Use only cleaning agents which have been approved by Sirona (see page 2, General information)! Wipe the SIROCAM C with a soft cloth. ATTENTION The camera handpiece with the cable CANNOT be ster- ilized or thermodisinfected! -
Page 32: Checking The Safety Switches
10 Checking the safety switches Sirona Dental Systems GmbH Care and cleaning instructions for the practice team C2 , M1 Checking the safety switches To ensure the safety of the practice team and the patients, please check the safety switches installed in the unit every 6 months. - Page 34 tÉ=êÉëÉêîÉ=íÜÉ=êáÖÜí=íç=ã~âÉ=~åó=~äíÉê~íáçåë=ïÜáÅÜ=ã~ó=ÄÉ=êÉèìáêÉÇ=ÇìÉ=íç=íÉÅÜåáÅ~ä=áãéêçîÉãÉåíëK «=páêçå~=aÉåí~ä=póëíÉãë=dãÄe=OMMN péê~ÅÜÉW=ÉåÖäáëÅÜ= mêáåíÉÇ=áå=dÉêã~åó a=PPTMKNMPKMNKNPKMO= MOKOMNM ûKJkêKW= NNO=QSM páêçå~=aÉåí~ä=póëíÉãë=dãÄe få=íÜÉ=rp^W RV=RU=RNO=a=PPTM c~Äêáâëíê~ëëÉ=PN páêçå~=aÉåí~ä=póëíÉãë=ii` lêÇÉê=kçK SQSOR=_ÉåëÜÉáã QUPR=páêçå~=aêáîÉI=pìáíÉ=NMM dÉêã~åó `Ü~êäçííÉI=k`=OUOTP ïïïKëáêçå~KÅçã...
