Eclipse Instructions for Use - US
Display Gain:
Controlled parameters:
Data collection:
Data Recovery:
A/D Resolution:
Sampling frequency
Artifact Reject System:
Rejection levels:
Anti aliasing filter:
Dots per Trace:
Low Pass Filter:
High Pass Filter:
DSP Low Pass Filter:
DSP High Pass Filter:
16 bit.
30 kHz
Standard voltage based system
Manual 0.2 - 640 µV input wuth 0.1uV steps.
Analog 5kHz, 24 dB / octave
450 displayed.
None or 17 – 12000 Hz, depending on the measurement type.
33 taps FIR Filter without wave peak latency displacement.
0.83 Hz to 500 Hz depending on the measurement type.
100, 300, 750, 1k, 1,5k, 2k, 3k, 4k, 5k, 7,5k Hz
0.5, 1.0, 3.3, 10, 33, 100 Hz
General Display Gain. Applicable during testing. Single Curve
Display Gain. Applicable during testing.
Stimuli Rate, Number of stimuli, Polarity, Click, Tone Burst
(Frequency, no. of sine waves, window), Stimulus intensity,
Number of curves per intensity, Intensity (Ascending,
Descending), Soft attenuator, Stimulus ear, Transducer, Masking
level, Preliminary filter setting, Recording onset, Automatic next
intensity (Wave repro level on screen), General Display Gain,
Single Curve Display Gain, Baseline, Latency norm, Report
templates, Print out, Manual stimulus to familiarization, Talk
Forward,
Impedance test,
Waveform buffer (A/B, Contra, Ipsi-Contra, A-B = Noise),
Curve (Hide, Fixate, Merge, Delete),
Online EEG,
Waveforms storage in unlimited storage database.
Lost data due to crash of Windows® will in almost all cases be
available upon re-establishing Windows® operation.
