Pin
Signal Description
2
Transmit/Receive Data 0 –
3
Transmit/Receive Data 1 +
4
Transmit/Receive Data 2 +
Related Information
"Server Overview" on page 12
■
"Rear Panel Components" on page 15
■
"Cabling Requirements" on page 51
■
"Connect the Ethernet Network Cables" on page 60
■
VGA Port
The server has two 15-pin VGA video ports, one port on the front and one on the back of the
server. See
"Front Panel Components" on page 14
Use a DB-15 video cable to connect to a video adapter to achieve the required connection. The
maximum supported resolution is 1024 x 768.
Only one of the two ports can be used at a time. The rear VGA port is disabled by
Note -
default. To enable the rear port and disable the front port, you must enable the Oracle ILOM
VGA_REAR_PORT policy. Type: ->
The cable length used to connect between the monitor and the VGA port should not be
Note -
over 6 meters.
Pin
Signal Description
6
Transmit/Receive Data 1 –
7
Transmit/Receive Data 3 +
8
Transmit/Receive Data 3 –
and
"Rear Panel Components" on page
set /SP/policy VGA_REAR_PORT=enabled
Identifying Ports
15.
.
Connecting Cables
57
