Identifying Ports
Pin
1
2
3
4
Related Information
"Server Overview" on page 12
■
"Rear Panel Components" on page 15
■
"Cabling Requirements" on page 51
■
"Connect the NET MGT Cable" on page 59
■
"Assign a Static IP Address to the NET MGT Port" on page 78
■
Ethernet Ports
Four RJ-45 10-Gigabit full-duplex auto-negotiating Ethernet ports (NET 0, NET 1, NET 2,
NET 3) are located on the system rear panel. See
Ethernet interfaces operate at 100 Mbit/sec, 1000 Mbit/sec, and 10000 Mbit/sec.
Pin
1
56
SPARC T7-4 Server Installation Guide • March 2017
Signal Description
Transmit Data +
Transmit Data –
Receive Data +
Common Mode Termination
Signal Description
Transmit/Receive Data 0 +
Pin
Signal Description
5
Common Mode Termination
6
Receive Data –
7
Common Mode Termination
8
Common Mode Termination
"Rear Panel Components" on page
Pin
Signal Description
5
Transmit/Receive Data 2 –
15. The
