2 Hardware Installation
WAN Connection
Figure 2.1 displays the application diagram for the connection of the modem, PC,
splitter, and telephone sets.
Power Socket
3G Connection
Figure 2.2 displays the connection when you would like to enjoy 3G network.
Power Socket
Installation
DCP-WR300N
Figure 2.1
Figure 2.2
