Rear Panel; Interface Description - DCP -WR300N User Manual

Blinking
Off
On
LAN(1~4) Blinking
Off
On
USB Blinking
Off

Rear Panel

Power ON/OFF LAN 1
The following table describes the interfaces and buttons of the device:
Interface
Reset
ON/OFF
Introduction
by WPS function.
WPS handshaking is in progress.
The WPS function is disabled.
There is a device connected to this LAN port.
Data is being transmitted over the corresponding LAN
port.
No device is connected to this LAN port.
3G modem is connected but no data being transmitted
Data is being transmitted over 3G modem
No device is connected to the USB port.
LAN 2 LAN 3 LAN 4 DSL
Description
Reset to the factory default configuration. Keep the device
powered on, and insert a needle into the hole for 3 seconds,
then release it. The device is reset to the factory default
configuration.
Power switch, power on or power off the device.
3
WPS/WIFI
Reset
DCP-WR300N
