Field
Channel Mode
Enable NAPT
Enable IGMP
IP Protocol
PPP Settings
User Name
Password
Type
Idle Time (min)
WAN IP Settings
Type
Local IP Address
Configuration
Description
You can choose 1483 Bridged, 1483 MER,
PPPoE, PPPoA, 1483 Routed or IPoA.
Select it to enable Network Address Port
Translation (NAPT) function. If you do not
select it and you want to access the Internet
normally, you must add a route on the uplink
equipment. Otherwise, the access to the
Internet fails. Normally, it is enabled.
You can enable or disable Internet Group
Management Protocol (IGMP) function.
Select this interface support ipv4
Enter the correct user name for PPP dial-up,
which is provided by your ISP.
Enter the correct password for PPP dial-up,
which is provided by your ISP.
You can choose Continuous, Connect on
Demand or Manual.
If set the type to Connect on Demand, you
need to enter the idle timeout time. Within the
preset minutes, if the router does not detect
the flow of the user continuously, the router
automatically disconnects the PPPoE
connection.
You can choose Fixed IP or DHCP.
If select Fixed IP, you should enter the
local IP address, remote IP address and
subnet mask.
If select DHCP, the router is a DHCP
client, the WAN IP address is assigned
by the remote DHCP server.
Enter the IP address of WAN interface
provided by your ISP.
17
