The following table describes the parameters and buttons of this page.
Field
IP QoS
QoS Policy
Schedule Mode
Source IP
Source Mask
Destination IP
Destination
Mask
Source Port
Destination Port
Protocol
Physical Port
Set priority
802.1p
delete
delete all
3.5.4 CWMP
Choose Advanced > CWMP, the page shown in the following page appears. In
this page, you can configure the TR-069 CPE.
Configuration
Description
Select to enable or disable IP QoS function. You need
to enable IP QoS if you want to configure the
parameters of this page.
You can choose stream based, 802.1p based or
DSCP based.
You can choose strict prior or WFQ (4:3:2:1).
The IP address of the source data packet.
The subnet mask of the source IP address.
The IP address of the destination data packet.
The subnet mask of the destination IP address.
The port of the source data packet.
The port of the destination data packet.
The protocol responds to the IP QoS rules. You can
choose TCP, UDP, ICMP or TCP/UDP.
The LAN interface responds to the IP QoS rules.
The priority of the IP QoS rules. P0 is the highest
priority and P3 is the lowest.
You can choose from 0 to 7.
Select a row in the QoS Rule list and click it to delete
the row.
Select all the rows in the QoS Rule list and click it to
delete the rows.
54
DCP-WR300N
