DCP -WR300N User Manual page 36

The following table describes the parameters of this page.
Field
SSID Type
Encryption
Set WEP Key
WPA Authentication
Configuration
Description
Service Set Identifier, is a name of a local area
network
Configure the wireless encryption mode. You can
choose None, WEP, WPA (TKIP), WPA (AES),
WPA2 (AES), WPA2 (TKIP) or WPA2 Mixed.
 Wired equivalent privacy0 (WEP) encrypts
data frames before transmitting over the
wireless network.
 Wi-Fi protected access (WPA) is a subset of
the IEEE802.11i security specification draft.
 WPA2 Mixed is the collection of WPA and
WPA2 encryption modes. The wireless client
establishes the connection between the
modem through WPA or WPA2.
Key differences between WPA and WEP are user
authentication and improved data encryption.
It is available when you set the encryption mode
to WEP. Click it, the Wireless WEP Key Setup
page appears.
 Select Personal (Pre-Shared Key), enter the
33 DCP-WR300N
