DCP -WR300N User Manual page 21

Field
Netmask
Unnumbered
Add
Modify
Delete
Current ATM VC Table
After proper settings, click Add and the following page appears.
Click in the PPPoE mode, the page shown in the following figure appears. In
this page, you can configure parameters of this PPPoE PVC.
Configuration
Description
Enter the subnet mask of the local IP
address.
Select this checkbox to enable IP
unnumbered function.
After configuring the parameters of this page,
click it to add a new PVC into the Current
ATM VC Table.
Select a PVC in the Current ATM VC Table,
then modify the parameters of this PVC. After
finishing, click it to apply the settings of this
PVC.
Select a PVC in the Current ATM VC Table,
and then click Delete to delete it
This table shows the existed PVCs. It shows
the interface name, channel mode, VPI/VCI,
encapsulation mode, local IP address,
remote IP address and other information. The
maximum item of this table is eight.
18
DCP-WR300N
