System Requirements; Features - DCP -WR300N User Manual

Interface
Power
LAN1~4
DSL
WiFi/WPS
1.3

System Requirements

Recommended system requirements are as follows:
Service subscriber
10 Base T/100 Base T Ethernet card
Hub or switch (attached to several PCs through one of Ethernet interfaces
on the device)
Operating system: Windows 98 SE, Windows 2000, Windows ME, Windows
XP, Windows Vista, Window 7
Internet Explorer V5.0 or higher, Netscape V4.0 or higher, or FireFox 1.5 or
higher
1.4

Features

The device supports the following features:
One DSL port, four 10/100Mbps auto-negotiation RJ45 ports, supports auto
MDI/MDIX.
Automatic 3G/WAN failover
Supports 3G/Dynamic IP/Static IP/PPPoE/L2TP/PPTP internet access
WLAN with high-speed data transmission rate, compatible with IEEE
802.11b/g/n, 2.4 GHz compliant equipment
Auto and multiple PVCs (eight at most)
DHCP server
Introduction
Description
Power interface, for connecting to the power adapter of DC
12V, 0.5A.
RJ45 interface, for connecting to the Ethernet interface of a
PC or the Ethernet devices through an Ethernet cable.
RJ11 interface, for connecting to the ADSL interface or a
splitter through a telephone line.
Press the button between 1s and 5s to enable WLAN
function.
Press the button for more than 5s to enable WPS (Wi-Fi
Protected Setup) function.
4
DCP-WR300N
