CHAPTER 1 PRODUCT OVERVIEW
Label
Power

Ethernet LED Descriptions

Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs.
Ethernet Link
Ethernet Speed

Specifications

Category
General
Features
Radio
Cellular
Wi-Fi, Bluetooth
Speed
Packet Data
SMS
SMS
Connectors
Cellular
Wi-Fi
SIM Holder
GPS
Power Requirements
Voltage
Physical Description
Dimensions
12
Description
9-32 VDC power receptacle for provided power cord. The device uses a Globtek GT-41052-
1509 9V 1.7A power supply.
Right LED on Ethernet connector. Blinks when there is transmit and receive
activity on the Ethernet link. It shows a steady light when there is a valid
Ethernet connection.
Left LED on Ethernet connector. Lit when the Ethernet is linked at 100 Mbps.
If it is not lit, the Ethernet is linked at 10 Mbps.
Description
HSPA+: 800*/850/900/1700*/1900/2100 MHz
GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Telit HE910-D
Murata LBEE5ZSTNC-523
Up to 7.2 Mbps downlink/5.76 Mbps uplink
Point-to-Point Messaging
Mobile-Terminated SMS
Mobile-Originated SMS
Female SMA connectors for cellular
Reverse polarity male SMA connector for Wi-Fi
Mini-SIM, standard 1.8 V and 3 V SIM receptacle
Female SMA connector
1
7 V to 32 V DC
Refer to the Dimensions topic that follows.
®
MultiConnect rCell 100 MTR-H5 User Guide
