GPS Antenna Specifications

Manufacturer:
Description:
Model Number:
Multi-Tech Part Number:

MultiTech Ordering Information

Model
ANGPS-1MM
ANGPS-10MM
ANGPS-50MM

Antenna Specifications

Category
Frequency Range
Impedance
VSWR
Gain
LNA Current Consumption
Noise Figure
Polarization
Input voltage

Bluetooth and Wi-Fi Antennas

Manufacturer:
Manufacturer's Model Number:
Multi-Tech Systems:
Multi-Tech Ordering Information
Model Number
ANWF-1HRA
ANWF-10HRA
ANWF-50HRA
®
MultiConnect rCell 100 MTR-H5 User Guide
Trimble
GPS Antenna with low noise amplifier
66800-52
45009665L
Quantity
1
10
50
Description
1575.24 MHz
50 Ohms
2.0:1 max
10-30 dBi
40 mA max
< 2dB
RHCP
3.0V M M 0.2V
Taoglas Antenna Solutions
GW.11.A153
45009740L
Quantity
1
10
50
CHAPTER 3 CELLULAR INFORMATION
