The associated run-time logs for this section.

Mail Log

Mail Log shows the recent email delivery attempts and the mail log details. Mail log entries are sorted by date with
the most recent on top. (This function is not available if you use PPP-IP Passthrough or Serial Modem mode). You
can select the number of emails to display in the queue. Possible values are 5, 10, 25, 50, or All emails.
1. Go to Status & Logs > Mail Log to display the Mail Log window.
2. To see the delivery details, click the eye icon under Options for the desired email entry.
3. To delete all mail log entries, click Purge Log.
Note:

Mail Queue

Mail Queue shows the emails that are waiting to be sent. The most recent email delivery attempts are on top. You
can select the number of emails to display in the queue. Possible values are 5, 10, 25, 50, and All emails. (This
function is not available if you use PPP-IP Passthrough or Serial Modem mode).
1. Go to Status & Logs > Mail Queue to display the Mail Queue window.
2. To view the delivery details for an individual email, click the eye icon under Options for the desired
email entry.
3. To delete all mail log entries, click Purge Log.
Note:

RF Survey

RF survey is not available for LTE models.
If you have a non-LTE device with a SIM card and want to perform an RF Survey, visit this link:
192.168.2.1/rf_survey.html and follow the instructions below. (The link uses the default IP address for the device
upon log in. If you change the IP address of the device, make sure to use that new IP address in the link).
After the RF Survey, you must reset the device in order to restore cellular radio functionality.
The RF Survey tool allows you to view the list of the cell towers that belong to the carrier and their signal quality
details such as Signal Level and Signal Noise Ratio. You need a SIM card to acquire the list of available cell towers.
Note: Selecting this tool terminates any existing PPP connection
1. Click on this link: 192.168.2.1/rf_survey.html to open the RF Survey page.
■
■
2. To view the Signal Strength chart of a carrier, under Options, click the eye icon for the carrier.
■
■
3. After the RF survey, reset your device. Go to Commands > Restart Device.
®
MultiConnect rCell 100 MTR-H5 User Guide
Logs do not persist through power cycles.
Logs do not persist through power cycles.
The search for the cell towers takes up to 2 minutes. The wait icon displays while the search is
in progress.
The cell tower to which the router is currently connected displays at the top of the list.
The Carrier Details window appears.
This feature helps you decide which area has better signal strength and thus a better location
for the router.
CHAPTER 13 DEVICE STATUS
75
