Label
Power

Ethernet LED Descriptions

Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs.
Ethernet Link
Ethernet Speed

Specifications

MTR-H6
Category
General
Performance
Frequency Bands
Radio
Cellular
Wi-Fi, Bluetooth
Speed
Packet Data
SMS
SMS
Connectors
Cellular
WiFi
SIM
GPS
Power Requirements
®
MultiConnect rCell 100 MTR-H6 Hardware Guide
Description
9-32 VDC power receptacle for provided power cord. The device uses a Globtek GT-41052-
1509 9V 1.7A power supply.
Right LED on Ethernet connector. Blinks when there is transmit and receive
activity on the Ethernet link. It shows a steady light when there is a valid
Ethernet connection.
Left LED on Ethernet connector. Lit when the Ethernet is linked at 100 Mbps.
If it is not lit, the Ethernet is linked at 10 Mbps.
Description
HSPA
GPRS/EDGE
Refer to the following RF Specifications table for details.
Telit HE910-EUD
Murata LBEE5ZSTNC-523
Up to 7.2 Mbps downlink/5.76 Mbps uplink This is theoretical maximum
speed.
Point-to-Point Messaging
Mobile-Terminated SMS
Mobile-Originated SMS
Female SMA connectors for cellular
Reverse polarity female SMA connectors for Wi-Fi
1.8 V and 3 V SIM holder for mini-SIM card
Female SMA connector
