7. To save your settings, click Save and Restart.

Ping and Reset Options

Perform a Ping Test
Ping allows you to test the IP address or URL to ensure it is operational.
To perform a ping test:
1. Go to Administration > Debug Options > Ping.
2. Enter the IP address or URL of the site you wish to ping.
3. Under Network Interface, choose from the available drop-down list options including: ANY, LAN,
CELLULAR, and ETHERNET.
4. Click Ping.
Reset Options
To reset the modem, go to Administration > Debug Options > Reset Options, click Reset Modem. If successful, the
system displays a message confirming a successful reset.

SMTP Settings

The following table lists the configuration fields in the SMTP window.
Field
SMTP Configuration
Enabled
Server
Port
Email
Username
Password
Mail Log Settings
Entries to Keep
Send a Test Email
Address
®
MultiConnect rCell 100 MTR-H5 User Guide
Description
Click to use the SMTP feature.
Enter the SMTP server address.
Enter the port number that the SMTP server uses.
Enter the sender email address. This address will be added as the
sender email address to the sent emails.
Enter the name that can access the SMTP server.
Enter the password that can access the SMTP server.
Enter the desired number of mail log entries that are to be stored
in the router. The range of values is 10 to 1000. If you click Submit,
this setting is not applied to the emails that are in progress or
deferred. Note that logs are not saved on the device. Also, logs do
not persist through power cycles.
To make sure that the SMTP is configured properly, enter a
destination email address, then click Send Test Email.
CHAPTER 12 DEVICE ADMINISTRATION
73
