Ethernet LED Descriptions

Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs.
Ethernet Link
Ethernet Speed

Specifications

Category
General
Performance
Frequency Bands
Radio
Cellular
Wi-Fi, Bluetooth
Speed
Packet Data
SMS
®
MultiConnect rCell 100 MTR-H5 User Guide
Right LED on Ethernet connector. Blinks when there is transmit and
receive activity on the Ethernet link. It shows a steady light when
there is a valid Ethernet connection.
Left LED on Ethernet connector. Lit when the Ethernet is linked at 100
Mbps. If it is not lit, the Ethernet is linked at 10 Mbps.
Description
HSPA+
GPRS/EDGE
Tri-Band 850/900/2100 MHz
Quad Band 850/900/1800/1900 MHz
Telit HE910-D
Murata LBEE5ZSTNC-523
Up to 7.2 Mbps downlink/5.76 Mbps uplink
PRODUCT OVERVIEW
