a. In the Protocol Support field, choose the internet protocol from the drop down menu (select from
IPv4 and IPv6).
b. In the Protocol Support field, choose IPv4 only as the cell radios for C2 and EV3 do not support IPv6.
c. In the IPv4/IPv6 Address field, type the router's IP address.
d. For IPv6, in the Prefix Length field, the length of the prefix displays. Users cannot change this field.
For IPv4, in the Mask field, type the mask for the network. The default is 255.255.255.0.
e. In the IPv6/IPv4 Primary DNS field, type the address of the primary DNS (optional).
Note: This is an optional value that can be used if you use a DNS server other than the servers
received from your carrier.
f. Click Next. Or if you are done making changes, click Finish.
If you select Network Router or Serial Modem mode, the following options are displayed:
a. In the IP Address field, type the router's IP address.
b. In the Mask field, type the mask for the network. The default is 255.255.255.0.
c. This field is only available in Network Router mode. If you select Serial Modem mode, skip this step.
In the IPv4 Primary DNS field, type the address of the primary DNS (optional).
Note: This is an optional value that can be used if you use a DNS server other than the servers
received from your carrier.
d. Click Next. Or if you are done making changes, click Finish.
5. This section is only available if you select Network Router or PPP-IP Passthrough mode. If you select
Serial Modem mode, skip this step. In the PPP Configuration page, configure PPP for your router.
a. To use PPP, check Enabled. When enabled, your device functions as a router.
b. For devices that use two antennas, Diversity is enabled by default. Diversity enables the use of two
cellular antennas for better performance. ( See Installing the Router for more details).
c. To enable the dial-on-demand feature, check Dial-on-Demand. This indicates to the router to bring
up the PPP connection when there is outgoing IP traffic, and take down the PPP connection after a
given idle timeout.
d. In the APN field, type the APN (Access Point Name). The APN is assigned by your wireless service
provider.
e. Click Next. Or if you are done making changes, click Finish.
6. This section is only available if you select Network Router or PPP-IP Passthrough mode. If you select
Serial Modem mode, skip this step. In the PPP Authentication page:
a. From Type, select the authentication protocol type used to negotiate with the remote peer: PAP,
CHAP, or PAP-CHAP. The default value is NONE.
b. In the Username field, type the username with which the remote peer authenticates. You can leave
this field blank, if desired. Username is limited to 60 characters.
c. In the Password field, type the password with which the remote peer authenticates. You can leave
this field blank, if desired. Password is limited to 60 characters.
7. This section is only available if you select Serial Modem mode. For any other mode, skip this step. In the
Serial Port Configuration page:
®
