CHAPTER 10 CONFIGURING SMS
3. Refer to the Required SMS Command Format field to see the format based on your chosen settings.
4. Click Submit.
5. To save your changes, click Save and Restart.
SMS Command Descriptions
The following table describes available SMS Commands under SMS Configuration > SMS Commands > Enabled
Commands. All SMS Commands are disabled by default. Check to enable.
SMS Command
#reboot
#checkin
#rm <enable|disable> <AccountKey>
#setcellular <enable|disable> [<APN>]
#ping [<interface>] [<count>] <address>
#apn
#cellular
#radio
#ethernet
#wan
Note: Arguments in square brackets [ ] are optional. Those in angle brackets < > are values.

Sending an SMS Message

To send an SMS message from the router:
1. Go to SMS > Send SMS to display the Send SMS window.
2. In the Recipient field, enter a phone number and click Add. You can add up to 100 phone numbers.
3. In the Message field, enter a text message up to 160 characters long.
4. Click Send. The system displays a confirmation indicating whether the message has been successfully sent
or not.

Viewing Received SMS Messages

To view received SMS messages from the router:
56
■
Enter the phone number and click Add Number.
■ Note: Due to differences between service providers, for every US number you add to
the Whitelist, create two separate entries: 1) one using the phone number and 2) the
other using 1 + phone number.
Description
reboots the device
TM
checks in to DeviceHQ
enable or disable remote management using DeviceHQ
(You must specify AccountKey when enabling Remote
Management if not previously configured.)
enable or disable Cellular and allows setting of the APN
ping IP address <count> times (range: 1-20, default = 4)
through <interface> (choose from cellular, wifi, and
ethernet or if not specified, the default gateway
interface is used)
get APN string
PPP status
radio status
Ethernet LAN configuration details
WAN transport type and WAN priority configuration
MultiConnect
®
rCell 100 MTR-H5 User Guide
